Rached Flanges, based in Tunis, Tunisia, has built a solid reputation as a reliable manufacturer and supplier of precision-engineered flanges for a variety of industrial sectors. Their product lineup is impressive, featuring DIN 2566 PN16 Threaded Flanges that are crafted with meticulous attention to DIN standards, ensuring top-notch quality and dependability. Thanks to their state-of-the-art production facilities, skilled technical team, and thorough quality control measures, Rached Flanges is known for delivering products that boast precise threading, consistent dimensions, and long-lasting durability. They cater to industries like water treatment, oil and gas, chemical processing, and infrastructure, always prioritizing high performance, prompt delivery, and customer satisfaction both locally and internationally.
When it comes to DIN 2566 PN16 Threaded Flanges, they are typically made from carbon steel, stainless steel, or various alloy steel grades as per DIN standards. This careful selection of materials guarantees excellent machinability, resistance to corrosion, and suitability for moderate pressure and temperature conditions. On the mechanical side, these flanges provide sufficient tensile and yield strength, good hardness, and resilience against mechanical stress for PN16 pressure ratings. The threaded design simplifies installation and maintenance, eliminating the need for welding while ensuring reliable sealing and structural integrity in low to medium pressure piping systems.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 95 | 14 | 65 | 20 | 35 | 45 | 2 | 4 | M 12 | 14 | 0,613 |
| 20 | 26,9 | R 3/4 | 105 | 16 | 75 | 24 | 45 | 58 | 2 | 4 | M 12 | 14 | 0,91 |
| 25 | 33,7 | R 1 | 115 | 16 | 85 | 24 | 52 | 68 | 2 | 4 | M 12 | 14 | 1,1 |
| 32 | 42,4 | R 1 1/4 | 140 | 16 | 100 | 26 | 60 | 78 | 2 | 4 | M 16 | 18 | 1,6 |
| 40 | 48,3 | R 1 1/2 | 150 | 16 | 110 | 26 | 70 | 88 | 3 | 4 | M 16 | 18 | 1,78 |
| 50 | 60,3 | R 2 | 165 | 18 | 125 | 28 | 85 | 102 | 3 | 4 | M 16 | 18 | 2,43 |
| 65 | 76,1 | R 2 1/2 | 185 | 18 | 145 | 32 | 105 | 122 | 3 | 4 | M 16 | 18 | 3,18 |
| 80 | 88,9 | R 3 | 200 | 20 | 160 | 34 | 118 | 138 | 3 | 8 | M 16 | 18 | 4,12 |
| 100 | 114,3 | R 4 | 220 | 20 | 180 | 38 | 140 | 158 | 3 | 8 | M 16 | 18 | 4,47 |
| 125 | 139,7 | R 5 | 250 | 22 | 210 | 40 | 168 | 188 | 3 | 8 | M 16 | 18 | 6,13 |
| 150 | 165,1 | R 6 | 285 | 22 | 240 | 44 | 195 | 212 | 3 | 8 | M 20 | 22 | 7,92 |
Rached Flanges, a leading supplier in Tunis, Tunisia, offers an extensive selection of DIN 2566 PN16 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
You’ll often find DIN 2566 PN16 Threaded Flanges in piping systems where welding isn’t practical or desired. They’re commonly used in applications like water supply networks, fire protection systems, compressed air lines, oil and gas utilities, and chemical processing plants. These flanges are perfect for low to medium pressure and temperature services, especially in environments that require careful maintenance or pose hazards. They facilitate the connection of pipes, valves, and fittings, making disassembly and system modifications a breeze. Adhering to DIN standards guarantees safe operation, compatibility, and reliable performance across a range of industries.
Yes, we offer custom sizes for DIN 2566 PN16 Threaded Flanges to meet specific project needs. Our team at Rached Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@rachedflanges.com.
